7 - MENU 5: MOTOR CONTROL
7.1 - List of parameters in Menu 5
Parameter Name Type Adjustment range Factory setting
User
setting
5.01 Output frequency RO/P ± 400.0 Hz - -
5.02 Output voltage RO/P 0 to 5.09 Volts - -
5.03 Output power RO/P 0 to 200 kW - -
5.04 Motor speed RO/P ± 2 x 1.06 rpm - -
5.05 DC bus voltage RO/P
Voltage code 200 : 0 to 420V
--
Voltage code 400 : 0 to 860V
5.06 Motor rated frequency R-W 0 to 400.0 Hz
Eur: 50.0 Hz
USA: 60.0 Hz
5.07 Motor rated current R-W 0 to drive rated current (A)
Motor rated
current
corresponding to
the rating
5.08 Motor rated speed R-W 0 to 9999 rpm
Motor rated
speed
corresponding to
the rating
5.09 Motor rated voltage R-W 0 to 480V
Eur L: 200V
USA L: 230V
Eur H: 400V
USA H: 460V
5.10 Rated power factor (cos ϕ) R-W 0 to 1.00 0.85
5.11 Number of motor poles R-W 0 to 4 0
5.12 Autotune R-W 0 to 2 0
5.13 Dynamic V to F R-W 0 or 1 0
5.14 Open loop mode select R-W 0 to 5 3 then 1
5.15 Boost R-W 0 to 25.0% of 5.09 0
5.16 Not used
5.17 Stator resistance R-W 0 to 32.000 Ω 0
5.18 Maximum switching frequency R-W 0 to 5 1
5.19 High stability modulation R-W 0 or 1 0
5.20 Quasi square output R-W 0 or 1 0
5.21
Not used
and
5.22
5.23 Voltage offset R-W 0 to 25.5 Volts 0 -
5.24 Transient inductance R-W 0 to 3200.0 mH 0
5.25 Stator inductance (Ls) R-W 0 to 3200.0 mH 150.0 mH
5.26
Not used
to
5.31
5.32 Motor torque per amp (Kt) R-W
0.01 to 320.00 NmA
-1
1.00 NmA
-1
5.33 Motor volt per 1000 rpm (Ke) R-W 0 to 10000 V 98 V
5.34 Speed display unit R-W 0 to 2 1
5.35
Disable automatic adjustment of the switching
frequency
R-W 0 or 1 0
5.36
Not used
to
5.50
5.51 q axis inductance R-W 0 to 999.9 mH 150.0 mH
5.52 Gearless optimisation R-W 0 or 1 0
5.53
Not used
to
5.57
: Function not available
