2.2.10 - Configuration 9: 05 = A.CtP
• Internal setting
2.2.11 - Configuration 10: 05 = HoiS
• Internal setting
Parameter Name Address
11
Not usedto
24
Parameter Name Value
1.14 Reference selector 1
6.04 Start/stop logic select 0
6.43 Run/Stop source 0
7.09 ADI1 input invert 0
7.10 ADI1 input destination 1.36
7.11 ADI2 mode 8
7.13 ADI2 input invert 0
7.14 ADI2 input destination 0
7.15 ADIO3 mode 1 0
7.17 ADIO3 input invert 0
7.18 ADIO3 input destination/output source 5.04
7.33 ADIO3 feature 4
8.10 Secure disable select 1
8.11 DIO1 input or output invert 0
8.12 DI2 input invert 0
8.13 DI3 input invert 0
8.14 DI4 input invert 1
8.17 Output relay invert 0
8.21 DIO1 input destination/output source 10.03
8.22 DI2 input destination 6.30
8.23 DI3 input destination 6.32
8.24 DI4 input destination 9.30
8.27 Output relay source 10.01
8.31 DIO1 input or output select 1
8.41 DIO1 feature 9
9.33 Binary sum destination 7.06
9.34 Binary sum output offset 4
Parameter Name Address
11
Not used
12 Preset reference 2 (PR2) 1.22
13
Not used
to
24
Parameter Name Value
1.10 Bipolar reference select 1
1.14 Reference selector 1
2.51 Ramp hold condition 1
6.04 Start/stop logic select 0
6.43 Run/Stop source 0
7.06 ADI1 mode 6
7.09 ADI1 input invert 0
7.10 ADI1 input destination 1.36
7.11 ADI2 mode 8
7.13 ADI2 input invert 0
7.14 ADI2 input destination 0
7.15 ADIO3 mode 7
7.17 ADIO3 input invert 0
7.18 ADIO3 input destination/output source 1.45
7.33 ADIO3 feature 4
8.10 Secure disable select 1
8.11 DIO1 input or output invert 0
8.12 DI2 input invert 0
8.13 DI3 input invert 0
8.14 DI4 input invert 0
8.17 Output relay invert 0
8.21 DIO1 input destination/output source 12.51
8.22 DI2 input destination 6.30
8.23 DI3 input destination 6.32
8.24 DI4 input destination 0
8.27 Output relay source 10.01
8.31 DIO1 input or output select 0
8.41 DIO1 feature 9
9.04 Logic function 1 source 1 8.04
9.05 Logic function 1 source 1 invert 1
9.06 Logic function 1 source 2 9.02
9.07 Logic function 1 source 2 invert 1
9.08 Logic function 1 output invert 0
9.10 Logic function 1 output destination 2.03
9.14 Logic function 2 source 1 1.45
9.16 Logic function 2 source 2 10.07
