ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 10: DRIVE STATES AND DIAGNOSTICS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
12.2.2 - Braking resistor and trip management configuration
Braking resistor alarm
Full power braking time
Full power braking period
Braking energy overload accumulator
Braking resistor
Drive reset
No. of auto-reset attempts
Auto-reset delay
Hold drive healthy until last attempt
Action on trip detection
User trip
User alarm 1
User alarm 2
User alarm 3
User alarm 4
User trip 1
User trip 2
User trip 3
User trip 4
Trip active at standstill
Trip auto reset when powered
Increase number of automatic trips
Trip management
10.30
10.33
10.34
10.35
10.36
10.37
10.38
10.54
10.55
10.56
10.57
10.61
10.63
10.65
10.67
10.69
10.70
10.91
10.31
10.12
10.39
