2.3 - Parameter 25 to 35
• If 25 = OP.LP (0 or 1)
• If 25 = cL.LP (2) or SrvO (3)
2.4 - Parameters 36 to 80
(*) For preset configuration 05 = Pump, the addresses for 46
to 58 are different.
See section 2.2.9 - Internal setting.
Parameter Name Address
25
Operating mode
11.31
Parameter Name Address
26
Open loop mode select 5.14
• If 26 = r.run (0) or r.no (1) or r.FSt (3) or r.On (4)
or SqrE (5)
27
Not usedto
30
31
Current loop P gain 4.13
32
Current loop I gain 4.14
33
Not usedto
35
• If 26 = UtoF (2)
27
Not usedand
28
29
Boost
5.15
30
Dynamic V to F
5.13
31
Not usedto
35
Parameter Name Address
26 Encoder type 3.38
27
Encoder lines per revolution
3.34
28
Drive encoder filter
3.42
29
Speed loop P gain Kp1
3.10
30
Speed loop I gain Ki1
3.11
31
Current loop P gain
4.13
32
Current loop I gain
4.14
33
Ramp bypass
2.02
34
Not usedand
35
Parameter Name Address
36
Brake controller enable
12.41
37
Upper current threshold
12.42
38
Lower current threshold
12.43
39
Brake release frequency
12.44
40
Brake apply frequency
12.45
41 Brake apply/magnetisation delay 12.46
42
Post-brake release delay
12.47
43
Brake apply delay
12.48
44
Not used
12.49
45
Not used
46 *
Start/stop logic select
6.04
47 *
Secure disable select
8.10
48 *
ADIO3 mode
7.15
49 *
ADIO3 feature
7.33
50 *
DIO1 feature
8.41
51 *
Jog reference
1.05
52 *
Bipolar reference enable
1.10
53 *
Skip (critical speed)
1.29
54 *
Skip reference band
1.30
55 *
Deceleration ramp mode select
2.04
56 *
S ramp enable
2.06
57 *
Stop mode
6.01
58 *
Mains loss mode
6.03
59
Catch a spinning motor
6.09
60
Maximum switching frequency
5.18
61
Motor rated frequency
5.06
62
Number of motor poles
5.11
63
Autotune
5.12
64
Parameter cloning
11.42
65
Factory setting
11.43
66
User security code
11.30
67
Parameter displayed at power-up
11.22
68
Selection of load display
4.21
69
Speed display unit
5.34
70
Parameter scaling
11.21
71
Last trip
10.20
72
Penultimate trip
10.21
73
ADI1 input level
7.01
74
ADI2 input level
7.02
75
ADIO3 input or output level
7.03
76
Pre-offset reference
1.60
77
Pre-ramp reference
1.03
78
Current magnitude
4.01
79
Motor speed
5.04
80
DC bus voltage
5.05
