2.2.9 - Configuration 8: 05 = Pump
• Internal setting
Parameter Name Address
11
ADI1 mode 7.06
12 ADI2 mode 7.11
13
PID proportional gain
14.10
14 PID integral gain 14.11
15 Stop on Vmin enable 14.56
16
Draining threshold
12.04
17 Draining time delay 16.05
18 Digital reference 14.51
19
Customer unit scaling coefficient
14.53
20 Reference input in customer units 14.54
21 Sensor input in customer units 14.55
22
Motor speed
5.04
23
Not usedand
24
Parameter Name Value
5.09 Motor rated voltage 4 0 0
7.06 ADI1 mode 6
7.10 ADI1 input destination 1.23
7.11 ADI2 mode 2
7.14 ADI2 input destination 1.24
7.15 ADIO3 mode 1 0
7.18 ADIO3 input destination/output source 10.90
7.33 ADIO3 feature 4
7.62 Block scaling 1 0 5
7.64 Scaling block destination 12.24
7.68 Scaling block source 12.12
8.11 DIO1 input or output invert 1
8.14 DI4 input invert 0
8.21 DIO1 input destination/output source 10.63
8.22 DI2 input destination 9.30
8.23 DI3 input destination 12.10
8.24 DI4 input destination 1.42
8.31 DIO1 input or output select 0
8.41 DIO1 feature 9
9.04 Logic function 1 source 1 12.01
9.06 Logic function 1 source 2 8.02
9.14 Logic function 2 source 1 9.01
9.16 Logic function 2 source 2 8.04
9.33 Binary sum destination 0
9.34 Binary sum output offset 0
9.64 Logic function 3 source 1 12.02
9.65 Logic function 3 source 1 invert 1
9.66 Logic function 3 source 2 14.56
9.74 Logic function 4 source 1 9.61
9.75 Logic function 4 source 1 invert 1
9.76 Logic function 4 source 2 14.56
9.78 Logic function 4 output invert 1
Parameter Name Value
11.01 Parameter 46 set-up 6.22
11.02 Parameter 47 set-up 6.23
11.03 Parameter 48 set-up 7.62
11.04 Parameter 49 set-up 10.20
11.05 Parameter 50 set-up 10.21
11.06 Parameter 51 set-up 10.22
11.07 Parameter 52 set-up 10.23
11.08 Parameter 53 set-up 10.24
11.09 Parameter 54 set-up 10.25
11.10 Parameter 55 set-up 10.26
11.11 Parameter 56 set-up 10.27
11.12 Parameter 57 set-up 10.28
11.13 Parameter 58 set-up 10.29
11.44 Quick setup menu access 1
12.03 Comparator 1 source 1.24
12.04 Comparator 1 threshold 200
12.05 Comparator 1 hysteresis 2 0
12.06 Comparator 1 output invert 1
12.08 Function 1 variable 1 source 1.23
12.09 Function 1 variable 2 source 1.22
12.11 Function 1 output destination 1.21
12.23 Comparator 2 source 1.24
12.25 Comparator 2 hysteresis 1 0
12.28 Function 2 variable 1 source 14.51
12.29 Function 2 variable 2 source 1.06
12.30 Function block 2 select 4
12.31 Function 2 output destination 1.22
12.33 Function 2 variable 1 scale 1 0
12.63 Comparator 3 source 9.32
12.64 Comparator 3 threshold 6 4
12.65 Comparator 3 hysteresis 0
12.67 Comparator 3 output destination 6.30
14.02 PID main reference source 1.21
14.03 PID reference source 1.21
14.04 PID feedback source 1.24
14.08 PID enable 1
14.09 PID option enable source 8.04
14.10 PID proportional gain 15000
14.11 PID integral gain 2000
14.16 PID output destination 1.36
14.53 Customer unit coefficient 1
14.56 Stop on V min enable 1
16.02 Timer relay 1 input source 9.02
16.05 Timer relay 1 value 1 0 0
16.09 Timer relay 1 output destination 10.61
16.12 Timer relay 2 input source 9.71
16.13 T i m e r r e l a y 2 t y p e 1
16.15 Timer relay 2 value 10 0
16.19 Timer relay 2 output destination 9.29
