8 - MENU 6: PROGRAMMABLE LOGIC AND TIMERS
8.1 - List of parameters in Menu 6
Parameter Name Type Adjustment range Factory setting
User
setting
6.01 Stop mode R-W 0 to 4 1
6.02 Not used
6.03 Mains loss mode R-W 0 to 2 0
6.04 Start/stop logic select R-W 0 to 2 0
6.05 Not used
6.06 DC injection braking level R-W 0 to 4.07 100.0%
6.07 DC injection braking time R-W 0 to 25.0 s 1 s
6.08 Hold zero speed R-W 0 or 1 0
6.09 Catch a spinning motor R-W 0 to 3 0
6.10 Enable reduced-voltage operation R-W 0 or 1 0
6.11 Enable keypad FWD key R-W 0 or 1
PT version: 1
PB version: 0
6.12 Enable keypad Stop key R-W 0 or 1 1
6.13 Enable keypad REV key R-W 0 or 1 0
6.14 Not used
6.15 Drive output R-W 0 or 1 1
6.16 Not used
6.17 Reset energy meter R-W 0 or 1 0
6.18
Not used
and
6.19
6.20 Powered-up time: years.days RO/P 0 to 9.364 years, days - -
6.21 Powered-up time: hours.minutes RO/P 0 to 23.59 hrs, min - -
6.22 Run time: years.days RO/P 0 to 9.364 (years, days) - -
6.23 Run time: hours.minutes RO/P 0 to 23.59 (hrs, min) - -
6.24 Energy meter: MWh RO/P 0 to 999.9 MWh - -
6.25 Energy meter: kWh RO/P 0 to 99.99 kWh - -
6.26
Not used
to
6.29
6.30 Sequencing bit: Run forward R-A 0 or 1 0 -
6.31 Sequencing bit: Jog R-A 0 or 1 0 -
6.32 Sequencing bit: Run reverse R-A 0 or 1 0 -
6.33 Sequencing bit: Forward/reverse R-A 0 or 1 0 -
6.34 Sequencing bit: Run R-A 0 or 1 0 -
6.35
Not used
to
6.38
6.39 Sequencing bit: Stop R-A 0 or 1 0 -
6.40
Not used
and
6.41
6.42 Control word R-W 0 to 32767 0
6.43 Run/Stop source R-W 0 to 3 0
6.44
Not used
to
6.50
6.51 Downstream contactor management R-W 0 or 1 0
6.52 Downstream contactor voltage R-W 0 to 25.0% 3.0%
6.53 Downstream contactor current threshold R-W 0 to 100.0% 10.0%
6.54 Downstream contactor status RO/P 0 or 1 - -
