MENU 16: PLC FUNCTIONS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
18 - MENU 16: PLC FUNCTIONS
18.1 - List of parameters in Menu 16
Parameter Name Type Adjustment range Factory setting
User
setting
16.01 - 16.11
Timer relays 1 to 4 output state RO 0 or 1 - -
16.21 - 16.31
16.02 - 16.12
Timer relays 1 to 4 input source R-W/P 0.00 to 21.51 0.00
16.22 - 16.32
16.03 - 16.13
Timer relays 1 to 4 mode select R-W 0 or 1 0
16.23 - 16.33
16.04 - 16.14
Timer relays 1 to 4 unit of time R-W 0 to 2 0
16.24 - 16.34
16.05 - 16.15
Timer relays 1 to 4 value R-W 0 to 60.0 0
16.25 - 16.35
16.06 to 16.08 Not used
16.09 - 16.19
Timer relays 1 to 4 output destination R-W 0.00 to 21.51 0.00
16.29 - 16.39
16.10 - 16.20
Timer relays 1 to 4 inverted output state RO/P 0 or 1 - -
16.30 - 16.40
16.16 to 16.18
Not used
16.26 to 16.28
16.36 to 16.38
16.41 - 16.51
Latching relays 1 to 4 output state RO 0 or 1 - -
16.61 - 16.71
16.42 - 16.52
Latching relays 1 to 4 ON source R-W 0.00 to 21.51 0.00
16.62 - 16.72
16.43 - 16.53
Latching relays 1 to 4 OFF source R-W 0.00 to 21.51 0.00
16.63 - 16.73
16.44 - 16.54
Latching relays 1 to 4 OFF source inversion R-W 0 or 1 0
16.64 - 16.74
16.45
to 16.48
Not used
16.50
16.55
to 16.58
16.60
16.65
to 16.68
16.70
16.75
to 16.78
16.49
- 16.59
Latching relays 1 to 4 output destination R-W 0.00 to 21.51 0.00
16.69
- 16.79
16.80 Current counter value RO 0 to 9999 - -
16.81 Counter output state RO 0 or 1 - -
16.82 Upcounting counter input R-A 0 or 1 - -
16.83 Downcounting counter input R-A 0 or 1 - -
16.84 Counter output trip threshold R-W 0 to 9999 0
16.85 Initial counter values R-W 0 to 9999 0
16.86 Counter power-up status R-W 0 or 1 0
16.87 Counter enable source R-W/P 0.00 to 21.51 0.00
16.88 Counter initialisation R-W 0 or 1 0
16.89 Counter output destination R-W/P 0.00 to 21.51 0.00
