Emerson Commander SX - 14 - Menu 12: Threshold Detectors, Variable Selectors and Brake Control Function; 14.1 - List of parameters in Menu 12

105
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 12: THRESHOLD DETECTORS, VARIABLE SELECTORS AND BRAKE CONTROL FUNCTION
CONTROL TECHNIQUES
3854 en - 03.2008 / b
14 - MENU 12: THRESHOLD DETECTORS, VARIABLE SELECTORS AND
BRAKE CONTROL FUNCTION
14.1 - List of parameters in Menu 12
: Function not available.
Parameter Name Type Adjustment range Factory setting
User
setting
12.01 - 12.02
Comparator 1 to 4 output RO 0 or 1 - -
12.61 - 12.71
12.03 - 12.23
Comparator 1 to 4 source R-W/P 0.00 to 21.51 0.00
12.63 - 12.73
12.04 - 12.24
Comparator 1 to 4 level R-W 0 to 100.0% 0
12.64 - 12.74
12.05 - 12.25
Comparator 1 to 4 hysteresis R-W 0 to 25.0% 0
12.65 - 12.75
12.06 - 12.26
Comparator 1 to 4 output invert R-W 0 or 1 0
12.66 - 12.76
12.07 - 12.27
Comparator 1 to 4 destination R-W/P 0.00 to 21.51 0.00
12.67 - 12.77
12.08 - 12.28 Function 1 and 2 variable 1 source R-W/P 0.00 to 21.51 0.00
12.09 - 12.29 Function 1 and 2 variable 2 source R-W/P 0.00 to 21.51 0.00
12.10 - 12.30 Function block 1 and 2 select R-W 0 to 9 0
12.11- 12.31 Function 1 and 2 output destination R-W/P 0.00 to 21.51 0.00
12.12- 12.32 Function block 1 and 2 output RO/P ± 100.00% - -
12.13- 12.33 Function 1 and 2 variable 1 scale R-W ± 4,000 1,000
12.14- 12.34 Function 1 and 2 variable 2 scale R-W ± 4,000 1,000
12.15- 12.35 Function 1 and 2 associated parameter R-W 0 to 100.00 0
12.16
Not used
to
12.22
12.36
Not used
to
12.39
12.40 Brake release RO 0 or 1 -
12.41 Brake controller R-W 0 to 3 0
12.42 Upper current threshold R-W 0 to 200% 10 %
12.43 Lower current threshold R-W 0 to 200% 10 %
12.44 Brake release frequency R-W 0 to 20.0 Hz 1.0 Hz
12.45
Brake apply frequency R-W 0 to 20.0 Hz 2.0 Hz
Brake apply speed R-W
0 to 100 rpm 5 rpm
12.46
Pre-brake release delay R-W
0 to 25.00 s
0.10 s
Brake apply delay R-W
0.30 s
12.47 Post-brake release delay R-W 0 to 25.00 s 0.10 s
12.48 Brake apply delay R-W 0 to 25.00 s 1.00 s
12.49 Position controller during brake release R-W 0 or 1 0
12.50 Not used
12.51 Forced brake release R-W 0 or 1 0
