10 - MENU 8: ASSIGNMENT OF DIGITAL INPUTS AND OUTPUTS
10.1 - List of parameters in Menu 8
Parameter Name Type Adjustment range Factory setting
User
setting
8.01 DIO1 input or output state RO/P 0 or 1 - -
8.02 DI2 input state RO/P 0 or 1 - -
8.03 DI3 input state RO/P 0 or 1 - -
8.04 DI4 input state RO/P 0 or 1 - -
8.05
Not used
and
8.06
8.07 Relay output status RO/P 0 or 1 - -
8.08 Not used
8.09 Secure disable input RO/P 0 or 1 - -
8.10 Secure disable select R-W/P 0 or 1 1
8.11 DIO1 input or output invert R-W 0 or 1 0
8.12 DI2 input invert R-W 0 or 1 0
8.13 DI3 input invert R-W 0 or 1 0
8.14 DI4 input invert R-W 0 or 1 0
8.15
Not used
and
8.16
8.17 Output relay invert R-W 0 or 1 0
8.18
Not used
and
8.19
8.20 Digital I/O read word RO 0 to 511 - -
8.21 DIO1 input destination/output source R-W/P 0.00 to 21.51 10.03
8.22 DI2 input destination R-W/P 0.00 to 21.51 6.30
8.23 DI3 input destination R-W/P 0.00 to 21.51 6.32
8.24 DI4 input destination R-W/P 0.00 to 21.51 1.41
8.25
Not used
and
8.26
8.27 Output relay source R-W/P 0.00 to 21.51 10.01
8.28
Not used
to
8.30
8.31 DIO1 input or output select R-W 0 or 1 1
8.32
Not used
to
8.40
8.41 DIO1 feature R-W 0 to 9 0
8.42
Not used
to
8.49
8.50 Buffer block R-W 0 or 1 0
8.51
Not used
to
8.60
8.61 FWD key status RO/P 0 or 1 - -
8.62 Stop key status RO/P 0 or 1 - -
8.63 REV key status RO/P 0 or 1 - -
8.64
Not used
to
8.70
8.71 FWD key invert R-W 0 or 1 0
8.72 Not used
8.73 REV key invert R-W 0 or 1 0
