4 - MENU 2: RAMPS
4.1 - List of parameters in Menu 2
Parameter Name Type Adjustment range Factory setting
User
setting
2.01 Post-ramp reference RO/P
If 1.10 = 0 and 2.02 = 0:
--
0 to 1.06
If 1.10 = 0 and 2.02 = 1:
1.07 to 1.06
If 1.10 = 1: ±
1.06
2.02
Ramp bypass ( )
R-W 0 or 1 0
2.03 Ramp hold R-W 0 or 1 0
2.04 Deceleration ramp mode select R-W 0 to 3 1
2.05 Not used
2.06 S ramp enable R-W 0 or 1 0
2.07 S ramp acceleration limit R-W
2 to 10 10
2.08 Standard ramp voltage R-W T = 0 to 800 V
Eur: 690V
USA: 750V
2.09 Not used
2.10 Acceleration rate selector R-W 0 to 9 1
2.11 Acceleration rate 1
R-W
0.1 to 600.0 s/1000 rpm 3.0 s/1000 rpm
to
to
2.18 Acceleration rate 8
2.19 Jog acceleration rate R-W
0.1 to 600.0 s/1000 rpm 0.2 s/1000 rpm
2.20 Deceleration rate selector R-W 0 to 9 1
2.21 Deceleration rate 1
R-W
0.1 to 600.0 s/1000 rpm 5.0 s/1000 rpm
to
to
2.28 Deceleration rate 8
2.29 Jog deceleration rate R-W
0.1 to 600.0 s/1000 rpm 0.2 s/1000 rpm
2.30
Not used
to
2.50
2.51 Ramp hold condition R-W 0 or 1 0
