Emerson Commander SX - 2.2.3 - Configuration 2: 05 = A2.Pr; 2.2.4 - Configuration 3: 05 = 4 Pr

14
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 0 CORRESPONDENCE AND AUTOMATIC PARAMETER SETTING
CONTROL TECHNIQUES
3854 en - 03.2008 / b
2.2.3 - Configuration 2: 05 = A2.Pr
• Internal setting
2.2.4 - Configuration 3: 05 = 4Pr
• Internal setting
Parameter Name Address
11 ADI1 mode 7.06
12 Preset reference 2 1.22
13 Preset reference 3 1.23
14 Preset reference 4 1.24
15
Not used
to
24
Parameter Name Value
1.14 Reference selector 1
1.15 Preset selector 0
6.04 Start/stop logic select 0
6.43 Run/Stop source 0
7.06 ADI1 mode 4
7.09 ADI1 input invert 0
7.10 ADI1 input destination 1.36
7.11 ADI2 mode 7
7.13 ADI2 input invert 0
7.14 ADI2 input destination 1.46
7.15 ADIO3 mode 1 0
7.17 ADIO3 input invert 0
7.18 ADIO3 input destination/output source 5.04
7.33 ADIO3 feature 0
8.10 Secure disable select 1
8.11 DIO1 input or output invert 0
8.12 DI2 input invert 0
8.13 DI3 input invert 0
8.14 DI4 input invert 0
8.17 Output relay invert 0
8.21
DIO1 input destination/output source
10.03
8.22 DI2 input destination 6.30
8.23 DI3 input destination 6.32
8.24 DI4 input destination 1.45
8.27 Output relay source 10.01
8.31 DIO1 input or output select 1
8.41 DIO1 feature 0
Parameter Name Address
11 Preset reference 1 1.21
12 Preset reference 2 1.22
13 Preset reference 3 1.23
14
Preset reference 4 1.24
15
Not used
to
24
Parameter Name Value
1.14 Reference selector 3
1.15 Preset selector 0
6.04 Start/stop logic select 0
6.43 Run/Stop source 0
7.06 ADI1 mode 7
7.09 ADI1 input invert 0
7.10 ADI1 input destination 1.46
7.11 ADI2 mode 8
7.13 ADI2 input invert 0
7.15 ADIO3 mode 1 0
7.17 ADIO3 input invert 0
7.18
ADIO3 input destination/output source
5.04
7.33 ADIO3 feature 0
8.10 Secure disable select 1
8.11 DIO1 input or output invert 0
8.12 DI2 input invert 0
8.13 DI3 input invert 0
8.14 DI4 input invert 0
8.17 Output relay invert 0
8.21
DIO1 input destination/output source
10.03
8.22 DI2 input destination 6.30
8.23 DI3 input destination 6.32
8.24 DI4 input destination 1.45
8.27 Output relay source 10.01
8.41 DIO1 feature 0
