Emerson Commander SX - 11.2 - Menu 9 Diagrams; 11.2.1 - Programmable Logic; 11.2.2 - Motorised Pot Function; 11.2.3 - Binary Sum Function

84
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 9: LOGIC FUNCTIONS, MOTORISED POT AND BINARY SUM
CONTROL TECHNIQUES
3854 en - 03.2008 / b
11.2 - Menu 9 diagrams
11.2.1 - Programmable logic
11.2.2 - Motorised pot function
11.2.3 - Binary sum function
Source 1 Source 2
Source 1
invert
Source 2
invert
Output invert Output state
Source
destination
Function 1 9.04 9.06 9.05 9.07 9.08 9.01 9.10
Function 2 9.14 9.16 9.15 9.17 9.18 9.02 9.20
Function 3 9.64 9.66 9.65 9.67 9.68 9.61 9.60
Function 4 9.74 9.76 9.75 9.77 9.78 9.71 9.70
Output
state
Destination
Source 1
Source 2
State 1
State 2
Invert
Invert
Invert
1
0
1
0
1
0
&
9.xx
9.x4
9.x6
9.x5
9.x8
9.x0
9.x7
Up
Down
Destination
Mode
%
+100
0
%
+100
–100
0
t
Reset
Bipolar
select
Rate
Scaling
Motorised
pot
output
9.26
9.27
9.28
9.03
9.21
9.24
9.25
9.22
9.23
Destination
0
0
0
0
1
1
1
1
0
1
2
3
4
5
6
7
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
Bit 0
Bit 1
Bit 2
+
Binary sum
output
Binary sum
offset
9.32
9.29
9.30
9.31
9.33
9.34
