ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 1: SPEED REFERENCE: SELECTION, LIMITING AND FILTERS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
3 - MENU 1: SPEED REFERENCE: Selection, limiting and filters
3.1 - List of parameters in Menu 1
Parameter Name Type Adjustment range Factory setting
User
setting
1.01 Speed reference selected RO/P ± 1.06 --
1.02 Pre-skip filter reference RO/P ± 1.06 or 1.07 to 1.06 --
1.03 Pre-ramp reference RO/P ± 1.06 or 1.07 to 1.06 --
1.04 Reference offset R-W
±
1.06
0
1.05 Jog reference R-W
0 to 1.06 rpm 45 rpm
1.06 Maximum reference clamp R-W
0 to 32000 rpm
Eur: 1500 rpm
USA: 1800 rpm
1.07 Minimum reference clamp R-W 0 to 1.06 0
1.08 Not used
1.09 Reference offset validation R-W 0 or 1 0
1.10 Bipolar reference select R-W 0 or 1 0
1.11 Reference enable indicator RO/P 0 or 1 - -
1.12 Reverse select indicator RO/P 0 or 1 - -
1.13 Jog select indicator RO/P 0 or 1 - -
1.14 Reference selector R-W 0 to 4 0
1.15 Preset selector R-W 0 to 9 0
1.16 Preset reference timer R-W 0 to 9999 s 0
1.17 Keypad reference R-W 1.07 to 1.06 (1.10 = 0) 0 -
1.18
Not used
to
1.20
1.21 Preset 1
R-W ± 1.06 0
to
to
1.28 Preset 8
1.29 Skip reference 1 R-W
0 to 1.06 rpm
0
1.30 Skip reference band 1 R-W
0 to 300 rpm 15 rpm
1.31 Skip reference 2 R-W
0 to 1.06 rpm
0
1.32 Skip reference band 2 R-W
0 to 300 rpm 15 rpm
1.33
Not used
and
1.34
1.35 Reference in skip zone RO/P 0 or 1 - -
1.36 Analog reference 1 R-A
1.07 to 1.06 (1.10 = 0)
--
± 1.06 (1.10 = 1)
1.37 Analog reference 2 R-A
1.07 to 1.06 (1.10 = 0)
--
± 1.06 (1.10 = 1)
1.38 Percentage trim R-W ± 100.0% 0
1.39
Not used
and
1.40
1.41
Reference selector R-A 0 or 1 - -
and
1.42
1.43
Not used
and
1.44
1.45
Preset reference select R-A 0 or 1 - -
to
1.47
1.48 Reference timer reset R-W 0 or 1 0
