MENU 1: SPEED REFERENCE: SELECTION, LIMITING AND FILTERS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
1.49 Selected reference indicator RO/P 1 to 4 - -
1.50 Selected preset reference indicator RO/P 1 to 8 - -
1.51 Power-up keypad reference R-W 0 to 2 0
1.52
Not used
to
1.59
1.60 Pre-offset reference RO
± 1.06
--
1.61
Not used
to
1.68
1.69 Number of preset references timed R-W 1 to 8 8
1.70 Scan time selection R-W 0 or 1 0
1.71 Preset 1 time R-W 0 to 9999 s 0
1.72 Preset 2 time R-W 0 to 9999 s 0
1.73 Preset 3 time R-W 0 to 9999 s 0
1.74 Preset 4 time R-W 0 to 9999 s 0
1.75 Preset 5 time R-W 0 to 9999 s 0
1.76 Preset 6 time R-W 0 to 9999 s 0
1.77 Preset 7 time R-W 0 to 9999 s 0
1.78 Preset 8 time R-W 0 to 9999 s 0
Parameter Name Type Adjustment range Factory setting
User
setting
To Next Page
