19
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 0 CORRESPONDENCE AND AUTOMATIC PARAMETER SETTING
CONTROL TECHNIQUES
3854 en - 03.2008 / b
2.2.12 - Configuration 11: 05 = Pad
• Internal setting
2.2.13 - Configuration 12: 05 = HuAC
• Internal setting
Parameter Name Address
11
Power-up keypad reference
1.51
12 Power-up keypad reference (Preset 1) 1.21
13
Enable FWD key 6.11
14
Enable Stop key 6.12
15
Enable REV key 6.13
16
Not usedto
24
Parameter Name Value
1.14 R e f e r e n c e s e l e c t o r 4
6.11 Enable local control FWD key 1
6.12 Enable local control Stop key 1
6.13 Enable keypad REV key 0
6.43 R u n / S t o p s o u r c e 2
7.11 ADI2 mode 8
7.15 A D I O 3 m o d e 1 0
7.18 ADIO3 input destination/output source 5.04
7.33 A D I O 3 f e a t u r e 0
8.10 Secure disable select 0
8.17 O u t p u t r e l a y i n v e r t 0
8.22 DI2 input destination 0
8.23 DI3 input destination 6.39
8.24 DI4 input destination 6.13
8.27 Output relay source 10.01
8.81 DIRF input destination 0
8.83 D I R R i n p u t d e s t i n a t i o n 0
Parameter Name Address
11
Not used
12 ADI2 mode 7.11
13
Not usedto
24
Parameter Name Value
1.14 Reference selector 0
6.04 Start/stop logic select 0
7.06 ADI1 mode 7
7.09 ADI1 input invert 0
7.10 ADI1 input destination 1.41
7.11 ADI2 mode 4
7.13 ADI2 input invert 0
7.14 ADI2 input destination 1.37
7.15 ADIO3 mode 1 0
7.17 ADIO3 input invert 0
7.18 ADIO3 input destination/output source 5.04
7.33 ADIO3 feature 4
8.10 Secure disable select 0
8.11 DIO1 input or output invert 0
8.12 DI2 input invert 0
8.13 DI3 input invert 0
8.14 DI4 input invert 0
8.17 Output relay invert 0
8.21 DIO1 input destination/output source 10.02
8.24 DI4 input destination 1.42
8.27 Output relay source 10.01
8.31 DIO1 input or output select 1
8.41 DIO1 feature 9
9.04 Logic function 1 source 1 8.04
9.06 Logic function 1 source 2 10.01
9.10 Logic function 1 output destination 9.30
9.33 Binary sum destination 6.43
9.34 Binary sum offset 0
9.64 Logic function 3 source 1 1.41
9.65 Logic function 3 source 1 invert 1
9.66 Logic function 3 source 2 8.04
9.67 Logic function 3 source 2 invert 1
9.68 Logic function 3 output invert 1
12.08 Function 1 variable 1 source 1.17
12.10 Function block 1 select 0
12.11 Function 1 output destination 1.21
12.13 Function 1 variable 1 scale 1000
12.15 Function 1 associated parameter 0
16.02 Timer relay 1 input source 9.61
16.03 Timer relay 1 type 0
16.04 Timer relay 1 unit of time 0
16.05 Timer relay 1 value 5
16.09 Timer relay 1 output destination 6.15
