MENU 7: ASSIGNMENT OF ANALOG INPUTS AND OUTPUTS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
9 - MENU 7: ASSIGNMENT OF ANALOG INPUTS AND OUTPUTS
9.1 - List of parameters in Menu 7
Parameter Name Type Adjustment range Factory setting
User
setting
7.01 ADI1 input level RO/P
0 to 100.0% (analog)
--
0.00% or 100.0% (digital)
7.02 ADI2 input level RO/P
0 to 100.0% (analog)
--
0.00% or 100.0% (digital)
7.03 ADIO3 input or output level RO/P 0 to 100.0% - -
7.04
Not used
and
7.05
7.06 ADI1 mode R-W 0 to 7 6
7.07 Not used
7.08 ADI1 input scaling R-W 0 to 2.50 1.00
7.09 ADI1 input invert R-W 0 or 1 0
7.10 ADI1 input destination R-W/P 0.00 to 21.51 1.36
7.11 ADI2 mode R-W 0 to 8 4
7.12 ADI2 input scaling R-W 0 to 2.50 1.00
7.13 ADI2 input invert R-W 0 or 1 0
7.14 ADI2 input destination R-W/P 0.00 to 21.51 1.37
7.15 ADIO3 mode R-W 0 to 10 10
7.16 ADIO3 scaling R-W
Input: 0 to 2.50
1.00
Output: 0 to 32.00
7.17 ADIO3 input invert R-W 0 or 1 0
7.18 ADIO3 input destination/output source R-W/P 0.00 to 21.51 5.04
7.19
Not used
to
7.26
7.27 ADI1 input current loop loss RO/P 0 or 1 - -
7.28 ADI2 input current loop loss RO/P 0 or 1 - -
7.29 ADIO3 input or output current loop loss RO/P 0 or 1 - -
7.30
Not used
to
7.32
7.33 ADIO3 feature R-W 0 to 4 0
7.34 IGBT junction temperature RO/P 0 to 200.0 °C - -
7.35
Not used
to
7.57
7.58 Minimum value of ADI1 R-W 0 to 1.00 0
7.59 Minimum value of ADI2 R-W 0 to 1.00 0
7.60 Minimum value of ADIO3 R-W 0 to 1.00 0
7.61 Minimum value of scaling block R-W 0 to 1.00 0
7.62 Block scaling R-W 0 to 2.50 1,00
7.63 Scaling block invert R-W 0 or 1 0
7.64 Scaling block destination R-W/P 0.00 to 21.51 0.00
7.65 PTC status RO/P 0 or 1 - -
7.66 Internal braking resistor temperature RO/P 0 to 200.0 °C - -
7.67 Local control potentiometer input RO/P 0 to 100.0% - -
7.68 Scaling block source R-W/P 0.00 to 21.51 7.67
7.69 Scaling block read RO/P ± 32000 - -
