Emerson Commander SX - 12.2 - Menu 10 Diagrams; 12.2.1 - Operating States

90
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 10: DRIVE STATES AND DIAGNOSTICS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
12.2 - Menu 10 diagrams
12.2.1 - Operating states
Overload alarm
Drive over temperature alarm
Drive warning
Trip 1 (most recent fault)
Trip 2
Trip 3
Trip 4
Trip 5
Trip 6
Trip 7
Trip 8
Trip 9
Trip 10 (oldest fault)
Decimal value of binary states
10.01 to 10.14
V
min
alarm
V
max
alarm
Maximum speed
Drive healthy
Drive active
Zero speed
Running at or below min speed
Below set speed
At speed
Above set speed
Load reached
Drive output is at current limit
Regenerating braking
Braking IGBT active
Direction commanded
Direction running
10.01 10.17
10.02 10.18
10.03 10.19
10.04 10.20
10.05 10.21
10.06 10.22
10.07 10.23
10.08 10.24
10.09 10.25
10.10 10.26
10.11 10.27
10.13 10.28
10.14 10.29
10.40
10.51
10.52
10.53
