38
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 3: FREQUENCY THRESHOLDS - ENCODER OPTION
CONTROL TECHNIQUES
3854 en - 03.2008 / b
3.47
Not used
to
3.50
3.51 Vmin alarm threshold R-W
0 to 500 rpm 90 rpm
3.52 V max alarm threshold R-W
0 to 500 rpm 90 rpm
3.53
Not used
to
3.60
3.61 Frequency input source R-W/P 0.00 to 21.51 0.00
3.62 Input frequency RO/P 0 to 5000 Hz -
-
3.63 Maximum frequency output reference R-W 0 to 1000.0 Hz 20.0 Hz
3.64 Frequency output reference scale R-W 0 to 32.00 1.00
3.65 Frequency output reference RO/P 0 to 100% -
-
3.66 Not used
3.67 Frequency input select R-W 0 or 1 0
3.68 Minimum frequency threshold R-W 1.0 to 10.0 Hz 1.0 Hz
3.69
Not used
and
3.70
3.71 Frequency output reference source R-W/P 0.00 to 21.51 0.00
3.72 Frequency output period RO/P 0.001 to 2.000 s -
-
3.73 Frequency output signal RO/P 0 or 1 -
-
Parameter Name Type Adjustment range Factory setting
User
setting
