FB107 LCD User Manual
2-4 Configuration Issued Sep-07
2.2 Configuring Touchpad Options
When configuring Touchpad options, you determine both the default
display mode (Sections 2.3 through 2.5) and which user IDs may access
which Touchpad features (Section 2.6).
You use the Configure option on the ROCLINK menu bar to select one
of two possible default display modes for the Touchpad.
Figure 2-6. ROCLINK 800 LCD User List Configuration Options
Option Description
Standard
Requires you to first log onto the Touchpad. Displays
(based on pre-defined ROCLINK 800 security
parameters) select system values and allows you
modify select system parameters.
Note: This is also called “Normal” mode.
BLM
Automatically displays up to 32 parameter values.
Allows you (based on pre-defined ROCLINK 800
security parameters) to log onto the Touchpad and
display select system values and modify select
system parameters.
Chart
Requires you to first log onto the Touchpad.
Displays, in a chart recorder format, historical or
dynamic values for up to 16 user-defined parameters.
Note: For convenience, a dynamic charting function
is available for the parameters displayed in
basic list mode. However, this is not the full-
function charting facility.
