FB107 LCD User Manual
Issued Sep-07 Configuration 2-7
6. Click Apply if you make any changes to this screen.
7. Click OK to close the LCD User List – BLM screen.
8. Proceed to Chapter 3, Using the Touchpad.
2.4 Configuring Standard or Normal Mode
In Standard or Normal mode, the Touchpad displays the Emerson
Process Management logos. When you touch the screen, a logon grid
displays. You then enter a PIN number to log on to the Touchpad.
1. Select the Advanced tab of the LCD Controller screen. The
Advanced screen displays.
Figure 2-9. ROCLINK 800 LCD User List Configuration Options, Advanced tab
2. Verify that Normal is selected in the LCD Mode frame. (This is the
factory default value for the Touchpad.)
3. Click Apply if you have needed to change the setting. ROCLINK
800 performs a warm start. The Touchpad now starts in Normal
mode.
