46 DCM00044 REV. 14
Figure 4.7 Electrical Connections from Power Supply to an Ultraweld L20 Actuator
Power Cord
Power Supply
Rear View
Ultraweld L20 Actuator
Rear View
J931CS
RF Cable
Analog Data
Cable
Control
Cable
IN CREASE
SPEED U P
SPEED D O W N
CO O LING
SIGNAL
ENCO D ER
DECREASE
50
Connect cooling
air hose
