Parameter
structure
Keypad and
display
Parameter x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Unidrive SP Advanced User Guide 15
Issue Number: 10 www.controltechniques.com
2.12 Special display functions
The following special display functions are used.
1. If the second motor map is being used the decimal point second
from the right of the first row is on.
2. When parameters are saved to a SMARTCARD the right-most
decimal point on the first row flashes for 2 seconds.
During power up one or more of the following actions may be required.
Each action may take several seconds, and so special display strings
are shown.
Display
string
Action
boot
If a SMARTCARD is present with Pr 11.42 set to boot the
parameters from the card must be transferred to the drive
EEPROM.
card
If the drive is in auto or boot mode (Pr 11.42 set to 3 or 4) the
drive ensures that the data on the card is consistent with the
drive by writing to the card.
loading
It may be necessary for a Solutions Module to transfer
parameter information from the drive. This is only carried out
if the parameter information held by the Solutions Module is
for a different drive software version. The drive allows up to
five seconds for this process.

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
