Emerson unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Unidrive SP Advanced User Guide 391
Issue Number: 10 www.controltechniques.com
Table 6-13 Parameter set-up to reproduce Macro 6 on a Unidrive SP
Parameter
Value
OL CL
1.10 Bipolar select On (1)
2.04 Ramp mode FASt
2.22 Deceleration rate 2 1.0 2.0
8.39 T28 & T29 digital input auto selection disable On (1)
8.25 T28 digital input 5 destination Pr 6.35
8.26 T29 digital input 6 destination Pr 6.36
9.04 Logic function 1 source 1 Pr 6.35 Pr 0.00
9.05 Logic function 1 source 1 invert On (1) OFF (0)
9.06 Logic function 1 source 2 Pr 6.36 Pr 0.00
9.07 Logic function 1 source 2 invert On (1) OFF (0)
9.08 Logic function 1 output invert On (1) OFF (0)
9.10 Logic function 1 destination Pr 2.35 Pr 0.00
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 8.05
11.05 Define Pr 0.15 Pr 8.03
11.06 Define Pr 0.16 Pr 8.04
11.07 Define Pr 0.17 Pr 8.06
11.08 Define Pr 0.18 Pr 6.01
11.09 Define Pr 0.19 Pr 6.08
11.10 Define Pr 0.20 Pr 2.22 Pr 0.00
11.11 Define Pr 0.21 Pr 8.15
11.12 Define Pr 0.22 Pr 8.16
11.13 Define Pr 0.23 Pr
0.00
11.14 Define Pr 0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 0.00
11.16 Define Pr 0.26 Pr 0.00
11.17 Define Pr 0.27 Pr 0.00
11.18 Define Pr 0.28 Pr 0.00
11.19 Define Pr 0.29 Pr 0.00
11.20 Define Pr 0.30 Pr 0.00

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
