Emerson unidrive sp User Manual

Menu 12
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
222 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
The variable selectors allow two source values (defined by Pr 12.08, Pr 12.28 and Pr 12.09, Pr 12.29) to be combined as defined by the mode
(Pr 12.10, Pr 12.30) to produce an output (Pr 12.12, Pr 12.32) which can be routed to the destination parameter (defined by Pr 12.11, Pr 12.31). The
actions of the variable selector are defined by the mode parameter as given below. If the mode parameter is changed or the variable selector is
disabled because neither source is routed to a valid parameter all the internal state variables (i.e. time constant accumulator, etc). within the selector
are reset. When the Sectional control mode is selected the function is also reset, and the output is held at zero, when the control (Pr 12.15 or
Pr 12.35) is zero. It is active when the control has a non-zero value.
12.13 Variable selector 1 source 1 scaling
12.33 Variable selector 2 source 1 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range
Open-loop, Closed-loop vector, Servo,
Regen
±4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate 4ms x number of menu 9 or 12 functions active read
12.14 Variable selector 1 source 2 scaling
12.34 Variable selector 2 source 2 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range
Open-loop, Closed-loop vector, Servo,
Regen
±4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate 4ms x number of menu 9 or 12 functions active read
12.15 Variable selector 1 control
12.35 Variable selector 2 control
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.00 to 100.00
Default
Open-loop, Closed-loop vector, Servo,
Regen
0.00
Update rate Background

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
