Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Unidrive SP Advanced User Guide 395
Issue Number: 10 www.controltechniques.com
Table 6-15 Parameter set-up to reproduce Macro 7 on a Unidrive SP
Parameter
Default(
Ö)
OL CL
2.04 Ramp mode FASt (0)
3.05 Zero speed threshold 2.0 2
5.27 Enable slip compensation OFF (0)
6.08 Hold zero speed On (1)
8.21 T24 digital I/O source / destination Pr 10.33
8.22 T25 digital I/O source / destination Pr 9.01
8.31 T24 digital output enable OFF (0)
8.32 T25 digital output enable On (1)
9.04 Logic function 1 source 1 Pr 12.01
9.06 Logic function 1 source 2 Pr 9.02
9.07 Logic function 1 source 2 invert OFF (0) On (1)
9.14 Logic function 2 source 1 Pr 10.01 Pr 1.11
9.15 Logic function 2 output invert OFF (0) On (1)
9.16 Logic function 2 source 2 Pr 10.03
9.17 Logic function 2 source 2 invert On (1) OFF (0)
9.19 Logic function 2 delay 0.2
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 4.01
11.05 Define Pr 0.15 Pr 12.01
11.06 Define Pr 0.16 Pr 10.01
11.07 Define Pr 0.17 Pr 10.03
11.08 Define Pr 0.18 Pr 9.01
11.09 Define Pr 0.19 Pr 12.04
11.10 Define Pr 0.20 Pr 9.19
11.11 Define Pr 0.21 Pr 0.00
11.12 Define Pr 0.22 Pr 0.00
11.13 Define Pr 0.23 Pr 0.00
11.14 Define Pr
0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 0.00
11.16 Define Pr 0.26 Pr 0.00
11.17 Define Pr 0.27 Pr 0.00
11.18 Define Pr 0.28 Pr 0.00
11.19 Define Pr 0.29 Pr 0.00
11.20 Define Pr 0.30 Pr 0.00
12.03 Threshold detector 1 source Pr 4.01
12.04 Threshold detector 1 level 10.00
12.05 Threshold detector 1 hysterisis 10.00
