Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menus 15 to 17
SM-I/O Plus
Unidrive SP Advanced User Guide 295
Issue Number: 10 www.controltechniques.com
x.40 Analog input 1
RO Bi NC PT
Ú
±100.0%
Ö
Update rate: 8ms x number of dumb modules
x.41 Analog input 1 scaling
RW Uni US
Ú
0 to 4.000
Ö
1.000
Update rate: Background read
x.42 Analog input 1 invert
RW Bit US
Ú
OFF (0) or On (1)
Ö
OFF (0)
Update rate: Background read
x.43 Analog input 1 destination
RW Uni DE PT US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on reset
x.44 Analog input 2
RO Bi NC PT
Ú
±100.0%
Ö
Update rate: 8ms x number of dumb modules
x.45 Analog input 2 scaling
RW Uni US
Ú
0.000 to 4.000
Ö
1.000
Update rate: Background read
x.46 Analog input 2 invert
RW Bit US
Ú
OFF (0) or On (1)
Ö
OFF (0)
Update rate: Background read
x.47 Analog input 2 destination
RW Uni DE PT US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on reset
x.48 Analog output 1 source
RW Uni PT US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on reset
x.49 Analog output 1 scaling
RW Uni US
Ú
0.000 to 4.000
Ö
1.000
Update rate: Background read

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
