Proline Promag 53 MODBUS RS485 Technical data
Endress+Hauser 117
MODBUS RS485:
• MODBUS device type: slave
• Address range: 1 to 247
• Functions codes supported: 03, 04, 06, 08, 16, 23
• Broadcast: supported with the function codes 06, 16, 23
• Physical interface: RS485 in accordance with standard EIA/TIA-485
• Baudrate supported: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 Baud
• Transmission mode: RTU or ASCII
•Parity:
RTU mode = NONE, EVEN, UNEVEN
ASCII mode = EVEN, UNEVEN
• Response time:
Direct data access = typically 25 to 50 ms
Auto-scan buffer (data area) = typically 3 to 5 ms
Signal on alarm Current output:
Failsafe mode selectable (e.g. in accordance with NAMUR recommendation NE 43)
Pulse / frequency output:
Failsafe mode selectable
Relay output:
De-energized by fault or power supply failure
MODBUS RS485:
If an error occurs, the value NaN (not a number) is output for the measured values.
Load see "Output signal"
Switching output Relay output:
Normally closed (NC or break) or normally open (NO or make) contacts available (default: relay 1
= NO, relay 2 = NC),
max. 30 V / 0.5 A AC; 60 V / 0.1 A DC, galvanically isolated.
Low flow cut off Switch points for low flow cut off are selectable.
Galvanic isolation All circuits for inputs, outputs, and power supply are galvanically isolated from each other.
