Proline Promag 53 MODBUS RS485 Technical data
Endress+Hauser 123
• AS 2129
– Table E (DN 80, 100, 150 to 1200)
• AS 4087
– PN 16 (DN 80, 100, 150 to 1200)
Promag P
• EN 1092-1 (DIN 2501)
– PN 10 (DN 200 to 600)
– PN 16 (DN 65 to 600)
– PN 25 (DN 200 to 600)
– PN 40 (DN 15 to 150)
•ANSI B 16.5
– Class 150 (½" to 24")
– Class 300 (½" to 6")
• JIS B2220
– 10 K (DN 50 to 300)
– 20 K (DN 15 to 300)
• AS 2129
– Table E (DN 25, 50)
• AS 4087
– PN 16 (DN 50)
Promag H
The permitted nominal pressure depends on the process connection and the seal:
• 40 bar → flange, weld nipple (with O-ring seal)
• 16 bar → all other process connections
Pressure tightness (measuring
tube lining)
Promag W
Promag P
Measuring tube lining: PFA
Promag W
nominal diameter
Measuring
tube lining
Resistance of measuring tube lining to partial vacuum: limit values for
absolute pressure [mbar] ([psi]) at various fluid temperatures
[mm] [inch]
25 °C 50 °C 80° C 100 °C 130 °C 150 °C 180 °C
77 °F 122 °F 176° F 212 °F 266 °F 302 °F 356 °F
25 to 1200 1 to 48" Polyurethane 0 0 - - - - -
65 to 2000 3 to 78" Hard rubber 0 0 0 - - - -
Promag P
nominal diameter
Resistance of measuring tube lining to partial vacuum: limit values for
absolute pressure [mbar] ([psi]) at various fluid temperatures
[mm] [inch]
25 °C 80° C 100 °C 130 °C 150 °C 180 °C
77 °F 176° F 212 °F 266 °F 302 °F 356 °F
251"000000
32-000000
401 ½"000000
502"000000
65-0*0000
803"0*0000
1004"0*0000
125-0*0000
1506"0*0000
2008"0*0000
* No value can be quoted.
