Proline Promag 53 MODBUS RS485 Technical data
Endress+Hauser 131
Process connection Promag W and Promag P
Flange connections:
• EN 1092-1 (DIN 2501)
–DN ≤ 300 = form A
–DN ≥ 350 = form B
– DN 65 PN 16 and DN 600 PN 16 exclusively according to EN 1092-1
•ANSI
• AWWA (Promag W only)
•JIS
•AS
Promag H
With O-ring:
• Weld nipple DIN (EN), ISO 1127, ODT/SMS
• Flange EN (DIN), ANSI, JIS
• Flange made of PVDF EN (DIN), ANSI, JIS
•External thread
•Internal thread
• Hose connection
•PVC adhesive fitting
With molded seal:
• Weld nipple DIN 11850, ODT/SMS
• Clamp ISO 2852, DIN 32676, L14 AM7
• Coupling DIN 11851, DIN 11864-1, ISO 2853, SMS 1145
• Flange DIN 11864-2
Surface roughness All data relate to parts in contact with fluid.
•Liner → PFA: ≤ 0.4 μm (15 μin)
• Electrodes: 0.3 to 0.5 μm (12 to 20 μin)
• Process connection made of stainless-steel (Promag H): ≤ 0.8 μm (31 μin)
