Proline Prowirl F 200 PROFIBUS PA Commissioning
Endress+Hauser 105
Configuring the pulse output
Navigation
"Setup" menu → Advanced setup → Pulse/frequency/switch output
Structure of the wizard for the pulse output
Operating mode
Pulse
Assign pulse
output
Value per pulse
Mass flow
Volume flow
Total mass flow
Corrected
volume flow
Energy flow
Heat flow
difference
Volume unit
Corrected
volume unit
Energy unit
Mass unit
Off
Energy unit
Pulse width
Failure mode
Invert output signal
End of wizard
Operating mode
A0020792-EN
 26 "Pulse/frequency/switch output" wizard in the "Advanced setup" submenu: "Operating mode"
parameter"Pulse" option
