Technical data Proline Prowirl F 200 PROFIBUS PA
204 Endress+Hauser
DN
1)
[in]
Pressure rating Weight
[lbs]
2 Class 150
Class 300
1.1
3 Class 150
Class 300
2.6
3.1
4 Class 150
Class 300
6.0
6 Class 150
Class 300
14.0
16.0
8 Class 150
Class 300
27.0
35.0
10 Class 150
Class 300
57.0
61.0
12 Class 150
Class 300
80.0
98.0
1) ASME
Materials Transmitter housing
Compact version
• Order code for "Housing", option B "Compact, stainless":
Stainless steel CF-3M (316L, 1.4404)
• Order code for "Housing", option C "Compact, aluminum coated":
Aluminum, AlSi10Mg, coated
• Window material: glass
Remote version
• Order code for "Housing", option J "Remote, aluminum coated":
Aluminum, AlSi10Mg, coated
• Order code for "Housing", option K "Remote, stainless":
For maximum corrosion resistance: stainless steel 1.4404 (316L)
• Window material: glass
Cable entries/cable glands
1
2
3
A0020640
 36 Possible cable entries/cable glands
1 Cable entry in transmitter housing, wall-mount housing or connection housing with internal thread M20 x
1.5
2 Cable gland M20 x 1.5
3 Adapter for cable entry with internal thread G ½" or NPT ½"
