GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / D/L FrameDly
Range
0 ~ 5000 msec
Default
100
Step
10 msec
Set Data Link frame Delay Time.
In case that D/L Confirm setting is OFF, it means Frame Interval time
when multi-frame occurs.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / D/L Retries
Range
0~ 2
Default
0
Step
1
Enter the number of retries that will be issued for a given data link
layer.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / D/L Timeout
Range
1 ~ 255 sec
Default
10
Step
1 sec
Set a waiting time between Data Link Frame transfer till to receive
Data Link Confirm(ACK) of Master. If there is no Data Link Confirm
receiving and Data Link retry is available, ETMFC610 will send Data
Link Frame again.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / A/L Retries
Range
0 ~ 255
Default
0
Step
1
Enter the number of retries of retransmission of unsol message
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / A/L Timeout
Range
1~ 255 sec
Default
30
Step
1 sec
Set a waiting time for Slave Application to receive Application layer
Confirm(ACK) from Master Application, in case that Confirm is
requested during Data transfer from Slave Application to Master
Application.
[DNP3 SLAVE1]
Function: DISABLE
Port Select:RS232-1
D/L Confirm: SOME
>D/L FrameDly: 100
D/L Retries: 0
[0~5000:10ms]
[DNP3 SLAVE1]
Function: DISABLE
Port Select:RS232-1
D/L Confirm: SOME
D/L FrameDly: 100
>D/L Retries: 0
[0~2:1]
[DNP3 SLAVE1]
Port Select:RS232-1
D/L Confirm: SOME
D/L FrameDly: 100
D/L Retries: 0
>D/L Timeout: 10
[1~255:1s]
[DNP3 SLAVE1]
>A/L Retries: 0
A/L Timeout: 30
Master Addr: 60000
Slave Address: 1
SBO Timeout: 15
[1~255:1s]
[DNP3 SLAVE1]
>A/L Retries: 0
>A/L Timeout: 30
>Master Addr: 60000
>Slave Address: 1
>SBO Timeout: 15
[1~255:1s]
