GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / Master Address
Range
0 ~ 65534
Default
60000
Step
1
Enter the master station address.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / Slave Address
Range
0 ~ 65534
Default
1
Step
1
Enter the slave(ETMFC610) address.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / SBO Timeout
Range
1 ~ 255 sec
Default
15
Step
1 sec
Set a time interval between Select Function and Operate Function. If
there is no operation command during set time, Select command is
cancelled.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / Init Unsol
Range
DISABLE, ENABLE
Default
ENABLE
Step
~
Select a use of re-start Initial Unsolicited Response.
 ENABLE : On Power Up, Initial Unsolicited Response Message is
transferred.
 DISABLE : On Power Up, Initial Unsolicited Response Message is
not transferred.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ DNP3 SLAVE1 / Unsol Time
Range
0 ~ 60 sec
Default
5
Step
1 sec
Set a delay time of reporting, in case Unsolicited mode event is
occurred. Reporting is conducted if no new Event is occurred within
the time.
[DNP3 SLAVE1]
A/L Retries: 15
A/L Timeout: 30
>Master Addr: 60000
Slave Address: 1
SBO Timeout: 15
[0~65534:1]
[DNP3 SLAVE1]
>A/L Retries: 15
>A/L Timeout: 30
Master Addr: 60000
>Slave Address: 15
>SBO Timeout: 15
[0~65534:1]
[DNP3 SLAVE1]
>A/L Retries: 15
>A/L Timeout: 30
>Master Addr: 60000
>Slave Address: 15
>SBO Timeout: 15
[1~255:1s]
[DNP3
SLAVE1]
>Init Unsol: ENABLE
Unsol Time: 5
Unsol Type: NOTRIG
Class1: ENABLE
Class2: ENABLE
[DISABLE/ENABLE]
[DNP3 SLAVE1]
>Init Unsol: ENABLE
>Unsol Time: 5
>Unsol Type: NOTRIG
>Class1: ENABLE
>Class2: ENABLE
[0~60:1s]
