GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ MULTI-BIT / M/S Mode
Range
SLAVE, MASTER
Default
SLAVE
Step
~
When using TCP or RS485 communication, select Slave or Master
mode.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ MULTI-BIT / Link IP Oct 1~4
Range
0 ~ 255
Default
0
Step
1
Set other party IP address at the use of Ethernet port.
IP Address : xxx.xxx.xxx.xxx
① ② ③ ④
Link IP Oct 1,2,3,4 is ①,②,③,④
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ MULTI-BIT / Link Timeout
Range
1 ~ 60000 msec
Default
15
Step
1 msec
On Ethernet communication, set the communication link timout time.
If communication link is not established during the set time, it is
determined that the communication is disconnected.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ MULTI-BIT / RMB Debounce
Range
1 ~ 100
Default
10
Step
1
Set pickup and dropout debounce count of the reception bit.
GLOBAL SETTING/ COMMUNICATION/ PROTOCOLS/ MULTI-BIT / ID Error Cnt
Range
1 ~ 100
Default
10
Step
1
Set the ID Error Count. If ID is received by this count, it is detected as
ID Error.
[
MULTI
-
BIT A
]
>TCP/UDP Select: TCP
>TCP Port: 21000
>UDP Port: 21001
>M/S Mode: SLAVE
>Link IP Oct1: 0
[ SLAVE/MASTER ]
[
MULTI
-
BIT A
]
>Link IP Oct1: 0
>Link IP Oct2: 0
>Link IP Oct3: 0
>Link IP Oct4: 0
>Link Timeout: 15
[ 0~255: 1 ]
[
MULTI
-
BIT A
]
>Link IP Oct1: 0
>Link IP Oct2: 0
>Link IP Oct3: 0
>Link IP Oct4: 0
>Link Timeout: 15
[ 1~60000: 1 ms ]
[
MULTI
-
BIT A
]
>Link Timeout: 15
>RMB Debounce: 10
>ID Error Cnt: 10
>CRC Error Cnt: 10
>Rx Error Cnt:
10
[ 1~100: 1 ]
[
MULTI
-
BIT A
]
>Link Timeout: 15
>RMB Debounce: 10
>ID Error Cnt: 10
>CRC Error Cnt: 10
>Rx Error Cnt:
10
[ 1~100: 1 ]
