Multi-Function Control ETMFC610 http://www.entecene.co.kr
197
EN
HANCED
TEC
HNOLOGY
GROUP # / PROTECTION / TIME OC-PHA / (+)TIME OC-PHA / Curve
Range
A(101), B(117), ..., DEF-10S (Total 62 curves)
Default
US-VI
Select desired curve type for (+) Phase time overcurrent element.
The T-C curves supported by the ETMFC610 are as follows;
 US
- US-NI : US Normally Inverse
- US-VI : US Very Inverse
- US-EI : US Extremely Inverse
- US-STI : US Short Time Inverse
- US-STVI : US Short Time Very Inverse
 ANSI /IEEE
- IEEE-NI : ANSI/IEEE Normally Inverse
- IEEE-VI : ANSI/IEEE Very Inverse
- IEEE-EI : ANSI/IEEE Extremely Inverse
 IEC
- IEC-NI : IEC Normally Inverse
- IEC-VI : IEC Very Inverse
- IEC-EI : IEC Extremely Inverse
- IEC-STI : IEC Short Time Inverse
- IEC-LTI : IEC Long Time Inverse
 ES
- ES-NI : KEPCO ESB Normally Inverse
- ES-VI : KEPCO ESB Very Inverse
- ES-EI : KEPCO ESB Extremely Inverse
- ES-LTVI : KEPCO ESB Long Time Very Inverse
 Definite Time : DEF-1s, DEF-10s
 KERI Curve : N1, N2, N3, N4
 User curves : USER-1,USER-2,USER-3,USER-4
 McGraw-Edison : Non Standard Curves 32
 Fuse curves : RI, HR, FR
For more details, refer to “Table 8-2. CB time-current operation
characteristic setting range”.
[
(+)TIME OC
-
PHA
]
Function: ENABLE
Pickup:
500
>Curve: [US-VI]
>Time Dial: 1.00
Time Add.: 0.00
[Curves : total 62]
