Table 8-2. CB time-current operation characteristic setting range
Setting 1 2 3 4 5 6 7 8 9 10
Curve
A(101) B(117) C(133) D(116) E(132) IEC-EI K(162) L(107) M(118) N(104)
Setting 11 12 13 14 15 16 17 18 19 20
Curve
IEC-NI P(115) R(105) T(161) V(137) IEC-VI W(138) Y(120) Z(134) 1(102)
Setting 21 22 23 24 25 26 27 28 29 30
Curve
2(135) 3(140) 4(106) 5(114) 6(136) 7(152) 8(113) 8*(111) 9(131) 11(141)
Setting 31 32 33 34 35 36 37 38 39 40
Curve
13(142) 14(119) 15(112) 16(139) 18(151) N1 N2 N3 N4 US-NI
Setting 41 42 43 44 45 46 47 48 49 50
Curve
US-VI US-EI ES-NI ES-VI USER-1 USER-2 USER-3 USER-4 DEF-1S DEF-10S
Setting 51 52 53 54 55 56 57 58 59 60
Curve
IEEE-NI IEEE-VI IEEE-EI US-STI US-STVI IEC-LTI IEC-STI ES-LTVI ES-EI RI
Setting 61 62
Curve
HR FR
GROUP # / PROTECTION / TIME OC-PHA / (+)TIME OC-PHA / Time Dial
Range
0.01 ~ 15.00
Default
1.00
Step
0.01
Set time dial, multiplying this value to selected T-C curve. Multiplying
this value changes the slope of the curve. Time dial is conducted after
time add application.
GROUP # / PROTECTION / TIME OC-PHA / (+)TIME OC-PHA / Time Add
Range
0.00 ~ 600.00 sec
Default
0.00
Step
0.01 sec
Set Time adder to add set value on selected T-C curve.
[
(+)TIME OC
-
PHA
]
Function: ENABLE
Pickup: 500
Curve: [US-VI]
>Time Dial: 1.00
Time Add.: 0.00
[0.05~15.00:0.01]
[
(+)TIME OC
-
PHA
]
Function: ENABLE
Pickup: 500
Curve: [US-VI]
Time Dial: 1.00
>Time Add.: 0.00
[0.00~600.00:0.01s]
