Multi-Function Control ETMFC610 http://www.entecene.co.kr
20
EN
HANCED
TEC
HNOLOGY
Phase Difference
Function ..................................................................... DISABLE/ENABLE
Dead Voltage Maximum Level .................................. 0.10 to 1.40xVT in steps of 0.01xVT
Live Voltage Minimum Level ................................... 0.10 to 1.40xVT in steps of 0.01xVT
Maximum Voltage Difference ................................... 0.10 to 1.40xVT in steps of 0.01xVT
Maximum Angle Difference ...................................... 1° to 100° in steps of 1°
Maximum Frequency Difference .............................. 0.01 to 5.00Hz in steps of 0.01Hz
Difference Check Phase ............................................ ALL/A/B/C
Time Delay ................................................................ 0.00 to 600.00sec in steps 0.01sec
Voltage Level Accuracy ............................................. 5%
Angle Level Accuracy ............................................... ±
Frequency Level Accuracy ........................................ at VT ± 0.02, at CVD ± 0.05
Timing Accuracy ....................................................... ± 5% of setting time or ± 20msec
Syncro’ Check
Function ..................................................................... DISABLE/ENABLE
Dead Voltage Maximum Level .................................. 0.10 to 1.40xVT in steps of 0.01xVT
Live Voltage Minimum Level ................................... 0.10 to 1.40xVT in steps of 0.01xVT
Maximum Voltage Difference ................................... 0.10 to 1.40xVT in steps of 0.01xVT
Maximum Angle Difference ...................................... OFF, 20.0° to 80.0° in steps of 0.1°
Maximum Frequency Difference (Slip Freq.) ........... 0.5 to 5.00Hz in steps of 0.01Hz
Syncro’ Check Phase ................................................. A/B/C/AB/BC/CA
Compensation Angle ................................................. 0° to 330° in steps of 30°
Load Side Voltage Compensation Factor .................. 0.50 to 2.00 in steps of 0.01
Switch(or CB) Closing Time ..................................... 0.00 to 600.0msec in steps 0.1msec
Closing Wait Time ..................................................... 1 to 600sec in steps 1sec
Voltage Level Accuracy ............................................. 5%
Angle Level Accuracy ............................................... ±
Frequency Level Accuracy ........................................ at VT ± 0.02, at CVD ± 0.05
Timing Accuracy ....................................................... ± 5% of setting time or ± 20msec
