GROUP # / MONITORING / SYNCHRO’ CHECK / Compens’ Angle
Range
0~330 degree
Default
0
Step
30 degree
When calculating the phase difference between the source side and the
load side, set the load side compensate angle. The load side angle is
the actual measured angle plus the set value.
GROUP # / MONITORING / SYNCHRO’ CHECK / Load-V Factor
Range
0.50~2.00
Default
1.00
Step
0.01
It is the compensation factor of the load side voltage magnitude. When
calculating the voltage difference between the source side and the load
side, it will apply this value to the load side voltage multiplied by this
set value.
GROUP # / MONITORING / SYNCHRO’ CHECK / Closing Time
Range
0.0~600.0 ms
Default
50.0
Step
0.1 ms
It sets the time to close the recloser. The phase difference calculation
value can be changed according to the switch(or CB) closing time.
GROUP # / MONITORING / SYNCHRO’ CHECK / CL Wait Time
Range
1~600 sec
Default
10
Step
1 sec
It sets synchronous detection input wait time. If the synchronous
condition is not satisfied during this set time after manual close
command, it does not close.
The front panel “25 PHASE DIFFERENCE” LED lights up when the
manual close command is in the standby state.
[
SYNCHRO
’
CHECK]
Angle Diff2: 30.0
Slip Freq.: 1.0
Sync Phase: A
>Compens’ Angle: 0
Load-V Factor: 1.00
[0~330:30 deg]
[
SYNCHRO
’
CHECK]
Angle Diff2: 30.0
Slip Freq.: 1.0
Sync Phase: A
Compens’ Angle: 0
>Load-V Factor: 1.00
[0.50~2.00:0.01]
[
SYNCHRO
’
CHECK]
Sync Phase: A
Compens’ Angle: 0
Load-V Factor: 1.00
>Closing Time: 50.0
CL Wait Time: 10
[0.0~600.0:0.1 ms]
[
SYNCHRO
’
CHECK]
Sync Phase: A
Compens’ Angle: 0
Load-V Factor: 1.00
Closing Time: 50.0
>CL Wait Time: 10
[1~600:1 s]
