DIAGNOSTIC EVENT RECORDER
 Trigger Source
 System Power(AC, Battery, ±12V, +5V)
 A/D Conversion(A/D Fail, Reference Voltage1, Reference Voltage 2)
 Power Down Mode
 Gas Status
 DSP Fail
 RTC Fail
 Memory Fail
 Flash-Rom Fail
 Circuit Voltage Fail
 Event Fail
 Count Fail
 DO Fail
 Close Fail
 Open Fail, etc.
 Trigger Time : every 5 msec
 Trigger type : Pick up and Dropout
 Storage Capacity : Last 2,000 Events
PQM EVENT RECORDER
 Trigger Source
 Interrupt Detect
 Voltage Sag Detect
 Voltage Swell Detect
 Voltage/Current Harmonics Detect
 Voltage/Current Unbalance Detect
 Under/Over Voltage Detect
 Under/Over Frequency Detect
 Trigger type : Pick up
 Storage Capacity : Last 1,500 Events
