Table 6-2. Initial Screen (2/3)
INITIAL SCREEN
Initial Screen 2
This screen displays current/voltage information on the line.
 Each phase current value is displayed (A,B,C,N,SEF) [A].
 Each phase voltage value is displayed (A,B,C,R,S,T) [kV].
Initial Screen 3
This screen displays current/voltage information on the line.
 Each phase current value is displayed (A,B,C,N,SEF) [A].
 Each phase-to-phase voltage value is displayed (AB,BC,CA,RS,ST,TR) [kV].
Initial Screen 4
This screen displays IRIG/GPS related with time synchronization.
STATUS: This screen displays time synchronization information.
 LINK SUCCESS: Time synchronization device is well installed.
 LINK FAIL: The connection of time synchronization is not normal.
 NOT INSTALL: Time synchronization device is not installed.
G: This screen displays UTC (Universal Time Coordinated) time.
L: This screen displays Local Time.
ⓐ This screen displays latitude received from time synchronization device.
(N: North, S: South).
ⓑ This screen displays longitude received from time synchronization device.
(E: East, W: West).
*. NOTE) If time synchronization device is not installed or at link fail,
local Information (latitude, longitude) is not displayed.
Initial Screen 5
This screen displays the version of ETMFC610.
CURRENT(A)/VOLT(kV)
IA: 00000 IB: 00000
IC: 00000 IG: 00000
SEF: 00.00
VA: 00.00 VR: 00.00
VB: 00.00 VS: 00.00
VC: 00.00 VT: 00.00
CURRENT(A)/VOLT(kV)
IA: 00000 IB: 00000
IC: 00000 IG: 00000
SEF: 00.00
AB: 00.00 RS: 00.00
BC: 00.00 ST: 00.00
CA: 00.00 TR: 00.00
GPS/IRIG MODULE
STATUS[ NOT INSTALL]
G01/01/2017 00:00:00
L01/01/2017 00:00:00
<
ⓐ
>
<
ⓑ
>
GPS/IRIG MODULE
STATUS[ NOT INSTALL]
G01/01/2017 00:00:00
L01/01/2017 00:00:00
<-: -D -M -S>
<-: -D -M -S>
CONTROLLER INFO
MPU: V1.0.0.0
DSP: V1.0.0.0
CPU: V1.0.0.0
HMI: V1.0.0.0
XML: ST00-1.00
OS : #001 2017-01-01
