Multi-Function Control ETMFC610 http://www.entecene.co.kr
Table 6-2. Initial Screen (3/3)
INITIAL SCREEN
Initial Screen 6
This screen displays loop control function. It can only display when control
type setting is “Fault Indication Type (FITYPE)”.
ⓐ Loop Control function are as below.
OFF : Loop Control function does not operate.
SEC : It operates as Auto Sectionalizer.
TIE : It operates as Tiepoint Switch.
- : Since control type is selected as “Protection Type (PROTYPE), auto
loop control function is not activated.
OPERATE ST: Displays the present operating status.
RESET : Reset status
RUNNING : Operation counter is increasing.
LOCKOUT : When at “SEC”, it displays. When operation counter is up to
maximum setting, switch will be at open operating.
CLOSING : When at “TIE”, it is standby status for close operation order.
OPENING : When at “TIE”, it is standby status for opening operation
order
52 CONTACT: It displays the status of switch(or CB)’s main contact
CLOSE: Displays main contact is closed.
OPEN: Displays main contact is opened.
TROUBLE: It is displayed in case of Contact status is incorrect or cable
connection is not completed.
SOURCE VOLT: Displays the status of source side voltage(LIVE or DEAD
LINE)
LOAD VOLT: Displays the status of load side voltage(LIVE or DEAD LINE)
O-COUNT SET : Displays the set operate count
O-COUNT NO. : Displays the present operate count
LOOP CONTROL <ⓐ>
OPERATE ST [ RESET]
52A CONTACT[ CLOSE]
SOURCE VOLT[ LIVE-L]
LOAD VOLT[ LIVE-L]
O-COUNT SET[ 4]
O-COUNT NO.[ 0]
OPERATE ST [ RESET]
52A CONTACT[ CLOSE]
SOURCE VOLT[ LIVE-L]
LOAD VOLT[ LIVE-L]
O-COUNT SET[ 4]
O-COUNT NO.[ 0]
To Next Page
