Table 7-1. Phase selection according to the reference voltage and phase rotation
Line feeding
Bushing Terminal
Recommend Setting Phase Mapping Result
Phase
Combination
Source Side LCD/INDEX Display :
Source V(Load V) / Current
Bushing/Controller
Terminal
Case 1 : abc abc 1V Va(Vr)/Ia A(R)/IA
ABC Vb(Vs)/Ib B(S)/IB
Vc(Vt)/Ic C(T)/IC
Case 2 : cab cab Va(Vr)/Ia B(S)/IB
ABC Vb(Vs)/Ib C(T)/IC
Vc(Vt)/Ic A(R)/IA
Case 3 : bca bca Va(Vr)/Ia C(T)/IC
ABC Vb(Vs)/Ib A(R)/IA
Vc(Vt)/Ic B(S)/IB
Case 4 : acb acb Va(Vr)/Ia A(R)/IA
ABC Vb(Vs)/Ib C(T)/IC
Vc(Vt)/Ic B(S)/IB
Case 5 : bac bac Va(Vr)/Ia B(S)/IB
ABC Vb(Vs)/Ib A(R)/IA
Vc(Vt)/Ic C(T)/IC
Case 6 : cba cba Va(Vr)/Ia C(T)/IC
ABC Vb(Vs)/Ib B(S)/IB
Vc(Vt)/Ic A(R)/IA
Case 7 : abc abc 2V Va(Vr)/Ia R(A)/IA
RST Vb(Vs)/Ib S(B)/IB
Vc(Vt)/Ic T(C)/IC
Case 8 : cab cab Va(Vr)/Ia S(B)/IB
RST Vb(Vs)/Ib T(C)/IC
Vc(Vt)/Ic R(A)/IA
Case 9 : bca bca Va(Vr)/Ia T(C)/IC
RST Vb(Vs)/Ib R(A)/IA
Vc(Vt)/Ic S(B)/IB
Case 10 : acb acb Va(Vr)/Ia R(A)/IA
RST Vb(Vs)/Ib T(C)/IC
Vc(Vt)/Ic S(B)/IB
Case 11 : bac bac Va(Vr)/Ia S(B)/IB
RST Vb(Vs)/Ib R(A)/IA
Vc(Vt)/Ic T(C)/IC
Case 12 : cba cba Va(Vr)/Ia T(C)/IC
RST Vb(Vs)/Ib S(B)/IB
Vc(Vt)/Ic R(A)/IA
