Multi-Function Control ETMFC610 http://www.entecene.co.kr
85
EN
HANCED
TEC
HNOLOGY
GLOBAL SETTING / GENERAL / MONITORING / PQM / INTERRUPT / Time
Range
0.5 ~ 10.0 cycle
Default
2.0
Step
0.5 cycle
Set a interrupt detecting time.
3) Sag
Place the curser on “ SAG” in PQM menu, press [ENT] button to move into this menu.
GLOBAL SETTING / GENERAL / MONITORING / PQM / SAG / Level
Range
0(OFF), 0.50~ 0.99 xVT
Default
OFF
Step
0.01 xVT
Set a voltage sag (low voltage) for Power Quality.
GLOBAL SETTING / GENERAL / MONITORING / PQM / SAG / Time
Range
0.5 ~ 10.0 cycle
Default
2.0
Step
0.5 cycle
Set a detect time for voltage sag (voltage low).
4) Swell
Place the curser on “SWELL” in PQM menu, press [ENT] button to move into this menu.
GLOBAL SETTING / GENERAL / MONITORING / PQM / SWELL / Level
Range
0(OFF), 1.01~ 1.50 xVT
Default
0
Step
0.01 xVT
Set a detect level of Voltage swell(high voltage) for Power Quality.
[INTERRUPT]
>Level: OFF
>Time: 2.0
[0.5~10.0:0.5cycle]
[SAG]
>Level: OFF
>Time: 2.0
0(OFF),0.50~0.99xVT
[SAG]
>Level: OFF
>Time: 2.0
[0.5~10.0:0.5cycle]
[SWELL]
>Level: OFF
>Time: 2.0
0(OFF),1.01~1.50xVT
