GLOBAL SETTING / GENERAL / MONITORING / PQM / SWELL / Time
Range
0.5 ~ 10.0 cycle
Default
2.0
Step
0.5 cycle
Set a time to detect voltage swell.
5) Harmonics
Place the curser on “HARMONIC” in PQM menu, press [ENT] button to move into this menu.
GLOBAL SETTING / GENERAL / MONITORING / PQM / HARMONICS / VTHD Pickup
Range
0(OFF), 0.5 ~ 100.0 %
Default
OFF
Step
0.1%
Set a detect level of voltage total harmonic distortion.
GLOBAL SETTING / GENERAL / MONITORING / PQM / HARMONICS / VTHD Delay
Range
0.00 ~ 600.00 sec
Default
1.00
Step
0.01 sec
Set a detect time to detect voltage total harmonic distortion.
GLOBAL SETTING / GENERAL / MONITORING / PQM / HARMONICS / ITHD Pickup
Range
0(OFF), 0.5 ~ 100.0 %
Default
OFF
Step
0.1%
Set a detect level of current total harmonic distortion.
[SWELL]
>Level: OFF
>Time: 2.0
[0.5~10.0:0.5cycle]
[HARMONICS]
>VTHD Pickup: OFF
>VTHD Delay: 1.00
>ITHD Pickup: OFF
>ITHD Delay: 1.00
[0(OFF),0.5~100.0%]
[HARMONICS]
>VTHD Pickup: OFF
>VTHD Delay: 1.00
>ITHD Pickup: OFF
>ITHD Delay: 1.00
[0.00~600.00:0.01s]
[HARMONICS]
>VTHD Pickup: OFF
>VTHD Delay: 1.00
>ITHD Pickup: OFF
>ITHD Delay: 1.00
[0(OFF),0.5~100.0%]
