RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
159
ENHANCED TECHNOLOGY
PRIMARY SETTING / PROTECTION / COLD LOAD PICKUP / CLPU-COMMON/ Make use ‘I’
Range
NO,YES
Default
NO
Step
~
This setting changes the point of time to activate a cold load pickup
function.
If “YES” is set, the cold load pickup function is activated when a load
current is restored (over 2A).
If “NO” is set, the cold load pickup function is activated when a
recloser is manually closed by local or remote control.
CLPU-TYPE1 Setup
This setting is to restrain the inrush current occurring at restoration of load supply.
PRIMARY SETTING / PROTECTION / COLD LOAD PICKUP / CLPU-TYPE1 / PHA
Range
10 ~ 20000A
Default
2000
Step
1A
Selects the raised pickup current for the phase overcurrent element
while cold load pickup feature is activated.
PRIMARY SETTING / PROTECTION / COLD LOAD PICKUP / CLPU-TYPE1 / GND
Range
10 ~ 20000A
Default
2000
Step
1A
Selects the raised pickup current for the ground overcurrent element
while cold load pickup feature is activated.
PRIMARY SETTING / PROTECTION / COLD LOAD PICKUP / CLPU-TYPE1 / SEF
Range*
4 ~ 2000A
Default
20
Step
1A
Selects the raised pickup current for the SEF overcurrent element while
cold load pickup feature is activated.
NOTE :
For the products that are dispatched with ZCT installed, the
setting range of this item is “0.4~200.0A (0.1A Step)”. It is
possible to check whether the product is dispatched with
ZCT installed by checking
“MAIN MENU/ STATUS/
CONTROL TYPE”
menu. Refer to
“9.4. Control Type”
.
[CLPU-TYPE1]
PHA(A): 2000
GND(A): 2000
>SEF(A): 20
[CLPU-TYPE1]
>PHA(A): 2000
>GND(A): 2000
>SEF(A): 20
[CLPU-TYPE1]
>PHA(A): 2000
GND(A): 2000
>SEF(A): 20
[CLPU-COMMON]
Function: TRIP
Relays(0-8): OFF
>Make use ‘I’: NO
