Entec EVRC2A-N6-NT - Page 56

RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
46
ENHANCED TECHNOLOGY
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / A/L Timeout
Range
1 ~ 255 sec
Default
55
Step
1 sec
Set a waiting time for Slave Application to receive A/L Confirm(ACK)
from Master Application, in case that Confirm is requested during Data
transfer from Slave Application to Master Application.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / SBO Time
Range
1 ~ 255 sec
Default
15 sec
Step
1 sec
Set a time interval between Select Function and Operate Function. If no
operation command during set time, Select command is cancelled.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / Multi Inter
Range
0.01 ~ 300.00 sec
Default
0.10
Step
0.01 sec
Enter a time delay between frames when Multi-frame replies.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / Tx Delay
Range
0.00(OFF), 0.01 ~ 300.00 sec
Default
0.05
Step
0.01 sec
Delay time of sending Real data after RTS Signal is on.
NOTE :
The setting does not apply to communication and is not
indicated from Ver 7.07 of EVRC2A_NT.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / PowUp Unsol
Range
DISABLE, ENABLE
Default
ENABLE
Step
~
Select the unsolicited mode.
Enable : Unsolicited response is transmitted.
Disable : Unsolicited response is not transmitted.
[DNP3.0-1]
>Multi Inter: 0.10
>Tx Delay : 0.05
>PowUpUnsol: ENABLE
[DNP3.0]
>DNP Address: 1
>Multi Inter: 0.10
>Tx Delay : 0.05
[DNP3.0-1]
>A/L Timeout: 55
>SBO Time: 15
>Multi Inter: 0.10
[DNP3.0-1]
A/L Retries: 1
A/L Timeout: 55
>SBO Time: 15
[DNP3.0-1]
D/L Timeout: 55
A/L Retries: 1
>A/L Timeout: 55
