COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / Time Req(m)
Range
0(OFF), 1 ~ 30000 min
Default
1440
Step
1 min
Set Time Sync in order to synchronize internal system clock with time
received from master station.
NOTE :
The setting is supported from Ver 7.04 of EVRC2A_NT.
5.2.2.2. IEC60870-5-101 Protocol - Option
EVRC2A can be programmed for communication using the IEC60870-5-101 through
communication port2 or port3.
Move to “PRIMARY, ALTERNATE or EDITBANK SETTING / RELAY SETUP /
COMMUNICATION / PROTOCOL SETUP / IEC60870-5-101” to select setting for IEC60870-
5-101 Protocol.
COMMUNICATION/ PROTOCOL SETUP/ IEC60870-5-101/ Function
Range
DISABLE, ENABLE
Default
DISABLE
Step
~
Select whether to use IEC60870-5-101 protocol.
COMMUNICATION/ PROTOCOL SETUP/ IEC60870-5-101/ Use Port
Range
P2-232, P3-232, P3-485
Default
P2-232
Step
~
Select a port to use IEC60870-5-101 communication.
COMMUNICATION/ PROTOCOL SETUP/ IEC60870-5-101/ Link Address
Range
0 ~ 65535
Default
1
Step
1
Enter the slave(EVRC2A) address for IEC60870-5-101 comm-
unication.
[IEC60870-5-101]
>Function: DISABLE
>Use Port:
P2-232
>Link Addr: 1
[IEC60870-5-101]
>Function: DISABLE
>Use Port P2-232
>Link Addr: 1
[IEC60870-5-101]
>Function: DISABLE
>Use Port:
P2-232
>Link Addr: 1
[DNP3 SLAVE1]
>K-Alv Check Tm: 10
>Fragment Size: 2048
>Time Req(m): 1440
