COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / Master IP Oct 1~4
Range
0 ~ 255
Default
~
Step
1
Select the IP Address for DNP3 Communication.
IP Address : 192
.xxx.xxx.xxx
① ② ③ ④
IP Addr´1,2,3,4 is ①,②,③,④
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / TCP/UDP Select
Range
TCP, UDP
Default
TCP
Step
~
Select TCP or UDT communication at the use of Port4(Ethernet).
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / TCP Port
Range
0 ~ 65535
Default
20000
Step
1
Set the TCP/IP port number of EVRC2A for TCP communication.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / UDP Port
Range
0 ~ 65535
Default
20000
Step
1
Set the TCP/IP port number of EVRC2A for UDP communication.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / Keep Alive Check Time
Range
0(OFF), 1 ~ 600 sec
Default
10
Step
1sec
Set the Time period that checks the communication connecting status
during the idle status.
COMMUNICATION / PROTOCOL SETUP / DNP1 or DNP2 / Fragment Size
Range
64 ~ 2048
Default
2048
Step
1
Set the size of DNP3.0 fragment.
[DNP3 SLAVE1]
>UDP Port: 20000
>K-Alv Check Tm: 10
>Fragment Size: 2048
[DNP3 SLAVE1]
>UDP Port: 20000
>K-Alv Check Tm: 10
>Fragment Size: 2048
[DNP3.0-1]
>TCP/UDP Select: TCP
>TCP Port: 20000
>UDP Port: 20000
[DNP3.0-1]
>TCP/UDP Select: TCP
>TCP Port: 20000
>UDP Port: 20000
[DNP3.0-1]
>TCP/UDP Select: TCP
>TCP Port: 20000
>UDP Port: 20000
[DNP3.0-1]
>Master IP Oct1: 192
>Master IP Oct2: 168
>Master IP Oct3:
7
>Master IP Oct4:
2
