5.2.5. EVENT&ETC
Move to “PRIMARY, ALTERNATE or EDITBANK SETTING / RELAY SETUP /
COMMUNICATION / EVENT&ETC”.
COMMUNICATION/ EVENT&ETC / AI Evt Method
Range
OFF,TH,DB,BOTH
Default
OFF
Step
~
Select the Analog Event Type. This setting value is applied only to the
AI point with vitalized “Event Active” in DNP point map.
OFF : AI Point Event doesn’t occur.
TH : Event occurs when the AI Point data is over or less than
Threshold value.
DB : Event occurs when the AI data change value is over the Deadband
value.
BOTH : TH and DB are both used.
Use EVRC2A interface program to set “Event Active” enable or disable
of AI point and the Threshold value and Deadband value.
COMMUNICATION/ EVENT&ETC / SKIP at Fault
Range
NO,YES
Default
YES
Step
~
Determine whether Threshold and Deadband AI event is generated
during Fault pickup.
COMMUNICATION/ EVENT&ETC / Fault ‘I’ Evt
Range
NO,YES
Default
YES
Step
~
NO : No Fault current event generated.
YES : Fault current event is generated at every fault sequence.
COMMUNICATION/ EVENT&ETC / BI Queue Size
Range
32,64,128,256
Default
256
Step
~
Set the Binary Queue Size.
[EVENT&ETC]
> BI Queue Size: 256
> BI Evt Mode: ALL
> AI Queue Size: 256
[EVENT&ETC]
> AI Evt Method: OFF
> SKIP at Fault: YES
> Fault ‘I’ Evt: YES
[EVENT&ETC]
> AI Evt Method: OFF
> SKIP at Fault: YES
> Fault ‘I’ Evt: YES
[EVENT&ETC]
> AI Evt Method: OFF
> SKIP at Fault: YES
> Fault ‘I’ Evt: YES
