Navigating WebView
Starting and Navigating WebView 2-5
Address Table Go to the Address Table Configuration screen, where you
can view entries in the device’s address table, add new static
address entries, remove entries, and view counts of dynamic
and static addresses in the address table.
STA Go to the STA Information, STA Configuration, and STA
Port Configuration screens, where you can view and
configure STA (Spanning Tree Algorithm) settings for the
device and for individual ports.
Bridge Extension Go to the Bridge Extension Configuration screen, where you
can view bridge MIB extension capabilities configured on
the device, and set the host VLAN ID.
Priority Go to the Port Priority Configuration and Port Traffic Class
Information screens, where you can set the default ingress
port priority per port, view the number of egress traffic
classes per port, and view port priority-to-transmit queue
mapping information.
VLAN Go to the VLAN Basic Information, VLAN Current Table,
VLAN Static List, VLAN Static Table, VLAN Static
Membership by Port, and VLAN Port Configuration screens.
Here you can view basic information about the numbers of
VLANs configured and about all static and dynamically
created VLANs known to the device, create new or remove
existing static VLANs from the device, configure a static
VLAN’s egress list, add ports to or remove ports from a
static VLAN, assign default VLAN IDs to untagged frames,
and enable or disable ingress filtering on one or more ports.
IGMP Go to the IGMP Configuration and the IP Multicast
Registration Table screens, where you can enable IGMP
(Internet Group Management Protocol) on the device,
configure IGMP parameters, and view the status of IGMP
groups.
Table 2-1 Screen Designations and Functions in the Navigation Frame (Continued)
Click on... To...
